P4-16S Indoor LED Display Specification Pixel distance：4（mm） Module size: 128X128（mm） Cabinet size：512×512×70（mm） Pixel density:62500dots/㎡ Color: 1R1G1B Module dots: 32*32=1024 DOTS Cabinet resolution:128*128 Cabinet size:0.262144m² Cabinet weight ：8.39KG±0.05KG Main specification Best viweing distance:4m～30m H ≧160° V ≥160° Ave power consumption＜500W/㎡ Max ＜1000w/㎡ Control way：synourphponous control Driver: DVI driver Scan method 1/16scan Max power consumption ≤20W Frame Frequency≧360Hz Brightness ≧800cd/㎡ Refresh rate ≧1920Hz Brightness Adjustment Automatic brightness sensor adjustment 16grade Manual adjustment：100grade Cooperation system WIN98、WINXP、WIN2000,etc Video Source RF、S-Video、RGB、RGBHV、YUV、YC、COMPOSITION etc Control system PCTV card（optional）+sending card+ revieving card+optical fiber transmission（optional） MTBF ≧5000Hrs Using life: 75000～100000Hrs defective rate ＜0.0002 dots Model: P4-16S 3 in 1 packaged 2121 led chips
